China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

Chi tiết sản phẩm

Nguồn gốc: Trung Quốc

Hàng hiệu: Beyde

Chứng nhận: CE

Số mô hình: 500/1+6

Điều khoản thanh toán và vận chuyển

Số lượng đặt hàng tối thiểu: 1 bộ

chi tiết đóng gói: Đóng gói container an toàn

Thời gian giao hàng: 90 ngày

Điều khoản thanh toán: L/C, D/A, D/P, T/T

Khả năng cung cấp: 200 bộ/năm

Nhận được giá tốt nhất
Chi tiết sản phẩm
Làm nổi bật:

500mm tubular stranding machine

,

big bearing tubular stranding machine

,

China manufacture tubular stranding machine

Cách sử dụng:
Mắc kẹt
Màu sắc:
Theo yêu cầu của khách hàng
Tên:
máy mắc cạn hình ống
Ứng dụng:
Thép, nhôm, dây thép bị mắc kẹt
Vật liệu dây:
thép, đồng
Cuộn thanh toán trung tâm:
PN400-PN630
Kích thước suốt chỉ Take-up:
PND800-PND1600
Đường kính dây trần tối đa:
4mm
Bảo hành:
12 tháng
Cách sử dụng:
Mắc kẹt
Màu sắc:
Theo yêu cầu của khách hàng
Tên:
máy mắc cạn hình ống
Ứng dụng:
Thép, nhôm, dây thép bị mắc kẹt
Vật liệu dây:
thép, đồng
Cuộn thanh toán trung tâm:
PN400-PN630
Kích thước suốt chỉ Take-up:
PND800-PND1600
Đường kính dây trần tối đa:
4mm
Bảo hành:
12 tháng
Mô tả sản phẩm



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine



This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.

Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.



Model 400 500 630
Inlet wire Dia.(mm) Conductor 1.5-3.5 1.8-4.0 2.0-5.0
Steel 1.0-2.5 1.5-3.0 1.8-4.0
Cores 1.2-3.5 1.5-5.0
Frame rotation speed(r/min) 700 600 400
Stranding Pitch(mm) 41-312 44-334
Linear Speed(m/min) 27-205.3 22-166.85 14-108.9
Capstan Dia.(mm) 800+1000 1000+1200 1000+1250
Size of tak-up bobbin PN1250 PN1600 PN1600



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 0

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 1

FAQ
1.Q: Where is your factory located? A: Our factory is located in HEJIAN CITY, HEBEI PROVINCE, CHINA,
we are near Beijing, Tianjin and Shijiazhuang air port, and CANGZHOU WEST high-speed railway station.
2.Q: What is the advantage about your company? A: Our company has skilled technical engineer and workers and professional production line.
3.Q: Why should l choose your products? A: We are direct manufacturer, we can ensure the stable product quality and provide in time service.
4.Q: The logo and the color can be customized? A: Yes
5.Q:What's your near sea loading port: Tianjin port
